$0.38 USD
Product Details
Key Specifications
-
Emitted Color: Brilliant Red
-
Dominant Wavelength: 624 nm
-
Peak Wavelength: 632 nm
-
Luminous Intensity: 250 to 500 mcd (typical at 20 mA)
-
Viewing Angle: 40°
-
Forward Voltage (V<sub>F</sub>): 1.7 V (min) to 2.4 V (max)
-
Forward Current (I<sub>F</sub>): 20 mA (typical), 25 mA (max continuous)
-
Peak Forward Current: 60 mA (1/10 duty cycle at 1 kHz)
-
Power Dissipation: 60 mW
-
Operating Temperature Range: -40°C to +85°C
-
Storage Temperature Range: -40°C to +100°C
-
Package Dimensions: 5.75 mm (L) x 5.75 mm (W) x 8.6 mm (H)
-
Lens Type: Red Diffused
-
Mounting Style: Through-Hole
-
Compliance: RoHS, REACH, and Halogen-Free
